74VHC74TTR
| Manufacturer Part | 74VHC74TTR |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IC FF D-TYPE DUAL 1BIT 14TSSOP |
| Category | Integrated Circuits (ICs) |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Obsolete |
| Function: | Set(Preset) and Reset |
| Type: | D-Type |
| Output Type: | Complementary |
| Number of Elements: | 2 |
| Number of Bits per Element: | 1 |
| Clock Frequency: | 115 MHz |
| Max Propagation Delay @ V, Max CL: | 9.3ns @ 5V, 50pF |
| Trigger Type: | Positive Edge |
| Current - Output High, Low: | 8mA, 8mA |
| Voltage - Supply: | 2V ~ 5.5V |
| Current - Quiescent (Iq): | 2 µA |
| Input Capacitance: | 7 pF |
| Operating Temperature: | -55°C ~ 125°C (TA) |
| Mounting Type: | Surface Mount |
| Supplier Device Package: | 14-TSSOP |
| Package / Case: | 14-TSSOP (0.173", 4.40mm Width) |
