Manufacturer Part | DB3X313F0L |
---|---|
Manufacturer | Panasonic Electronic Components |
Description | DIODE ARRAY SCHOTTKY 30V MINI3 |
Category | Discrete Semiconductor Products |
RoHS | Lead free / RoHS Compliant |
Warranty | 365 days |
Datasheet | - |
Type | Description |
---|---|
Product Status: | Discontinued at Digi-Key |
Diode Configuration: | 1 Pair Series Connection |
Diode Type: | Schottky |
Voltage - DC Reverse (Vr) (Max): | 30 V |
Current - Average Rectified (Io) (per Diode): | 200mA |
Voltage - Forward (Vf) (Max) @ If: | 550 mV @ 200 mA |
Speed: | Small Signal =< 200mA (Io), Any Speed |
Reverse Recovery Time (trr): | 1.5 ns |
Current - Reverse Leakage @ Vr: | 50 µA @ 30 V |
Operating Temperature - Junction: | 125°C (Max) |
Mounting Type: | Surface Mount |
Package / Case: | TO-236-3, SC-59, SOT-23-3 |
Supplier Device Package: | MINI3-G3-B |
