APV1121SZ
| Manufacturer Part | APV1121SZ |
|---|---|
| Manufacturer | Panasonic Electric Works |
| Description | OPTOISO 2.5KV PHOTOVOLTAIC 4-SOP |
| Category | Isolators |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Number of Channels: | 1 |
| Voltage - Isolation: | 2500Vrms |
| Current Transfer Ratio (Min): | - |
| Current Transfer Ratio (Max): | - |
| Turn On / Turn Off Time (Typ): | 400µs, 100µs |
| Rise / Fall Time (Typ): | - |
| Input Type: | DC |
| Output Type: | Photovoltaic |
| Voltage - Output (Max): | 8.7V |
| Current - Output / Channel: | 14µA |
| Voltage - Forward (Vf) (Typ): | 1.15V |
| Current - DC Forward (If) (Max): | 50 mA |
| Vce Saturation (Max): | - |
| Operating Temperature: | -40°C ~ 85°C |
| Mounting Type: | Surface Mount |
| Package / Case: | 4-SMD, Gull Wing |
| Supplier Device Package: | 4-SOP |
