Product Attributes
| Type | Description |
|---|---|
| Product Status: | Obsolete |
| Number of Channels: | 1 |
| Inputs - Side 1/Side 2: | 1/0 |
| Voltage - Isolation: | 5000Vrms |
| Common Mode Transient Immunity (Min): | 15kV/µs |
| Input Type: | DC |
| Output Type: | Open Collector |
| Current - Output / Channel: | 15 mA |
| Data Rate: | 1Mbps |
| Propagation Delay tpLH / tpHL (Max): | 750ns, 500ns |
| Rise / Fall Time (Typ): | - |
| Voltage - Forward (Vf) (Typ): | 1.65V |
| Current - DC Forward (If) (Max): | 25mA |
| Voltage - Supply: | 4.5V ~ 30V |
| Operating Temperature: | -40°C ~ 100°C |
| Mounting Type: | Surface Mount |
| Package / Case: | 8-SMD, Gull Wing |
| Supplier Device Package: | 8-DIP Gull Wing |
