Product Attributes
| Type | Description |
|---|---|
| Product Status: | Discontinued at Digi-Key |
| Technology: | Optical Coupling |
| Number of Channels: | 1 |
| Voltage - Isolation: | 5000Vrms |
| Common Mode Transient Immunity (Min): | 25kV/µs |
| Propagation Delay tpLH / tpHL (Max): | 250ns, 250ns |
| Pulse Width Distortion (Max): | 100ns |
| Rise / Fall Time (Typ): | 50ns, 50ns |
| Current - Output High, Low: | 2A, 2A |
| Current - Peak Output: | 2.5A |
| Voltage - Forward (Vf) (Typ): | 1.56V |
| Current - DC Forward (If) (Max): | 25 mA |
| Voltage - Output Supply: | 15V ~ 30V |
| Operating Temperature: | -40°C ~ 110°C |
| Mounting Type: | Through Hole |
| Package / Case: | 8-DIP (0.400", 10.16mm) |
| Supplier Device Package: | 8-DIP |
| Approval Agency: | CSA, SEMKO, UL |
